Navien NFC-250/200H 210,000 BTU

Product Description:

This high-efficiency residential gas boiler, part of the NFB-H Series, is designed for both residential and commercial applications. With a robust electronic ignition system and a power source of gas, this boiler is engineered for reliable performance.

Specifications:

• AFUE (Annual Fuel Utilization Efficiency): 0.95, ensuring excellent energy efficiency.
• Capacity: 4.50 gallons, accommodating various heating needs.
• Diameter: 17-3/10 inches, compact enough for versatile installations.
• Height: 27-3/5 inches, designed to fit in standard installation spaces.
• End Connection: NPT (National Pipe Thread), standard for easy integration.
• Material: Constructed from Cold Rolled Carbon Steel for durability.
• MBH (Thousand BTUs per Hour): 210, providing substantial heating power.
• Power Source: Operates on gas for effective heating.
• Ignition System: Electronic Ignition for reliable starting.
• Installation Type: Indoor Wall Hung, optimizing space usage.
• Vent Type: Forced Draft Direct, enhancing performance and efficiency.
• Volts: 120V, suitable for standard electrical systems.
• Supply Pipe Connection Size: 1-1/4 inches for secure connections.

Certifications and Compliance:

• Energy Star Compliant: Yes, confirming adherence to energy efficiency standards.
• Green Product: Yes; Energy Star certified, reflecting its eco-friendly design.
• Specifications – ANSI: ANSI Z21.13, meeting industry standards.
• Specifications – ASME: Yes, ensuring compliance with additional standards.
• Specifications – CSA Certified: CSA 4.9-2017, for additional certification and safety.
